BROUAV D30L-8 Pesticide Spraying Drone
D30L-8 is suitable for pesticide spraying in farmland. The device also has a line feed function when spraying pesticides. It can also complete automatic spraying of the area by controlling the background, which greatly improves the work efficiency. After spraying the medicine carried by the 30 kg plant protection drone D30L-8, it can return to the breakpoint to continue the spraying operation, which can avoid repeated spraying. The use of small agricultural drones in large-scale farmland can improve the ability to control pests and diseases in a timely manner.
Features:
- The airframe adopts a closed design, which can prevent pesticides from entering the flight control system and provide safety protection for long-term operations;
- The plant protection machine has a built-in GPS and compass module, which has a fixed altitude and fixed point flight function, which can well maintain the spray height and spray route accuracy of the operation;
- The spraying operation height limit and flight speed limit can be set. The high-pressure spraying system has good atomization effect. Under the wind pressure of the aircraft, the drug mist has strong penetrability. The particles of the drug mist can reach the stem and crops. Leaf facial.
- Modular design of functional components, easy maintenance and upgrade.
- Using smart plug-in battery
- Add radar air shock absorption
- Using high-pressure brushless water pump, the ESC is fully waterproof. At the same time, the pump increases air shock absorption
- The whole machine is optimized and the circuit is hidden.
- The folding part is 7075 aviation aluminum (high grade), and the arm is folded in the form of thread.
- Dedicated 30L medicine barrel, increase medicine inlet and medicine outlet, and can upgrade medicine and fertilizer (solid particle fertilizer) machine. There is no longer a need to replace barrels with liquid pesticides and solid particulate fertilizers. Convenient.
Technical Specifications
Specifications
Product material
Aviation carbon fiber + aviation aluminum
Product extended size
3090mm x 3090mm x 830mm
Product folding size
890mm x 750mm x 1680mm
Packaging size
1800mm x 1000mm x 900mm
Maximum takeoff weight
52KG
Aircraft weight
19KG
Pesticide Barrel
30L
Flight altitude
≤30 meters
Fly time(unloaded)
20~30 minutes
Fly time(loaded)
10~13minutes when fully loaded
Flight speed
1-10 m / sec
Structure lift span
≥10 years
Spray width
6-12 meters
Hovering in the air
Hovering in any direction
Spray flow
3-10L/min water pump adjustable
Spray system
Imported high pressure anti-floating atomizing nozzle
Atomization point size
60~90μm
Fly control
Industrial Version GPS and Controller
Spray efficiency
≥10hectares / hour
Safe takeoff and landing wind speed
≤5
Motor speed
5000rpm
Power system
50.4V power polymer computer battery
Charger
AC Input 100-240V
Lithium-polymer battery
16000mAh*\ c 2
Package Content
For Package Contents, please send email to: info@nomadx.store
