660m Range 15kg Payload Hybrid Powered VTOL UAV Fixed Wing Drone with camera
This Gyrocopter is a versatile platform with a long endurance and large payload capacity. Its tilt-rotor vertical take-off on landing (VTOL) design allows it to autonomously take-off and land in an area as small as 4m x 4m. Using large front-tilting high-speed it can hover like a multi-rotor more steadily and take-off and land in very heavy wind. The servos will even tilt to a certain level to compensate for wind, which keeps the plane steadier during take-offs and landings. Mission Control is fully supported for easy, fully autonomous surveying with precise camera triggering based on mission parameters. Its payload capabilities are very adaptable, thanks to its 15kg max capacity and large available mounting volume.
Technical Specifications
Length2.6mWingspan3.8mHeight770mmWing area2.5m²Landing gear formFour-point parallel landing gearTank capacity12L/14.5LMaximum speed (at sea face level)140km/hrsCruising speed110km/hrsStall speed24m/sOperation on the seaYes, for maritime versionEndurance8h (payload=0kg)@850E
6hrs@5kg payload@850E
5hrs@5kg payload@850Maximum Altitude for take-off2,500m AMSLPayload10kg@4 hrs (for 850E)
5kg@6 hrs (for 850E)Max payload15kg@2 hrs@850EMaximum Range660km @payload=5kgMax take-off weight50kgNavigation modeGPS/BDSConsumption of fuel3.5L/hrsEngine for taking off and landingElectricity powered brushless motorEngine for cruisingOil-powered two stroke carburetor engineWind load rating (Positive crosswind)5 grade (8.0~10.8m/s) when cruising
3 grade (3.4~5.4 m/s) when takingoff/landingLowest operating Temperature-20℃ for Anti-ice version
6℃ for ordinary versionTaking off modeVerticallyLanding modeVerticallyCelling3,000m for ordinary version
5,000m for plateau versionOperating humidity≤90%RHPackage Contents
